Library ／ Cleaning ／ Mobile robot system having a plurality of exchangeable work modules and method of controlling the same
Source reports Expired

Mobile robot system having a plurality of exchangeable work modules and method of controlling the same

US-8918950-B2

Abstract

Disclosed is a mobile robot system having a plurality of exchangeable work modules, thereby providing a mobile robot capable of performing various functions at a low cost. The mobile robot system comprises a plurality of work modules, which perform different works, respectively; a module station for connecting the plurality of work modules; and a mobile robot, which selects and connects to one of the plurality of work modules from the module station according to a work task to be performed. The mobile robot autonomously operates to perform the work task.

Patent figures（8）

US-8918950-B2 figure 1
1
US-8918950-B2 figure 2
2
US-8918950-B2 figure 3
3
US-8918950-B2 figure 4
4
US-8918950-B2 figure 5
5
US-8918950-B2 figure 6
6
US-8918950-B2 figure 7
7
US-8918950-B2 figure 8
8
