一种可混合两种液体的容器,便于即时混合。
专利摘要
一种用于混合两种液体等的容器,包括:容器;设置在容器顶部向上延伸的倾倒筒;形成在容器上位于倾倒筒下方的朝上台阶部分;内周表面拧到倾倒筒外周表面上的盖;放置在盖内侧的小容器;形成小容器底表面的可切割第一片材;设置在盖底端并介于盖和朝上台阶部分之间的可移除筒,其在盖拧到倾倒筒上之前从盖移除;以及设置在容器上以面向放置在盖内侧的小容器底表面的第一切割器,其中通过将盖拧到倾倒筒上使小容器接近第一容器,然后第一片材被第一切割器切割。
Original abstractA container for mixing two liquids and the like includes: a container; a pouring cylinder that is provided extending upwards on a top portion of the container; an upward facing step portion that is formed on the container so as to be positioned below the pouring cylinder; a cap whose inner circumferential surface is screwed onto an outer circumferential surface of the pouring cylinder; a small container that is placed on an inner side of the cap; a cuttable first sheet that forms a bottom surface of the small container; a removable cylinder that is provided at a bottom end of the cap and is interposed between the cap and the upward facing step portion, and that is removed from the cap prior to the cap being screwed down onto the pouring cylinder; and a first cutter that is provided on the container so as to face a bottom surface of the small container that is placed on the inner side of the cap, wherein the small container is made to approach the first container as a result of the cap being screwed down onto the pouring cylinder, and the first sheet is then cut by the first cutter.
专利附图(8)
