用于手持清洁，方便排空集尘容器。
专利摘要
一种手持式真空吸尘器，具有壳体、电机风扇单元、集尘容器、通向集尘容器的空气通道，含尘空气通过该通道被引导进入集尘容器，以及至少一个在流动方向上设置在集尘容器之后的过滤器。集尘容器具有第一排空口，该排空口通常由盖子覆盖，其尺寸设计成当盖子打开时允许集尘容器中收集的灰尘通过该口落下。集尘容器还具有第二排空口。在一个方面，第二排空口适于通过连接件与外部真空源流体连接。在另一方面，提供了一种类似的装置，并适于使得集尘容器可以在不从真空吸尘器上移除的情况下通过第一排空口排空。在另一方面，本发明提供了一种真空吸尘器集尘容器，其具有空气入口、空气出口、第一污物出口和第二污物出口。第一和第二污物出口与空气出口分离。
Original abstractA hand held vacuum cleaner having a housing, a motor-fan unit, a dust container, an air passage opening into the dust container and through which dust laden air is directed into the dust container, and at least one filter arranged after the dust container, as seen in the flow direction. The dust container has a first emptying opening, which is normally being covered by a lid and is sized such that it allows the dust collected in the dust container to fall out through the opening when the lid is opened. The dust container also has a second emptying opening. In one aspect, the second emptying opening is adapted to be fluidly connected to an external vacuum source via a connection. In another aspect, a similar device is provided, and adapted so the dust container can be emptied through the first emptying opening without removing the dust container from the vacuum cleaner. In another aspect, the invention provides a vacuum cleaner dust container having an air inlet, an air outlet, a first dirt outlet, and a second dirt outlet. The first and second dirt outlets are separate from the air outlet.
专利附图（8）
