用于含水家用电器的电接口
Electric interface for water-bearing household devices
US-8197610-B2一种用于控制含水家电的电气接口，简化布线。
专利摘要
提供了一种用于含水家用电器的电接口，包括程序控制，用于以灵活和模块化的布置经济地控制操作控制含水家用电器所需的水力和电气组件。电子组件和电磁阀的至少一部分集成到连接到含水设备的程序控制的组件组中。由于将液压电磁阀与用于控制组件组中的电磁阀的电子组件集成，减少了各个电磁阀和程序控制之间的必要电连接。用于液压组件和电子组件的电连接的电缆形式的复杂性降低，从而能够实现相关组件的模块化构造。组件组的设备可根据每个家用电器设计而变化。
Original abstractAn electric interface for water-bearing household devices is provided comprising a program control for economically controlling, in a flexible and modular arrangement, hydraulic and electrical components which are required for the operational control of the water-bearing household device. At least one part of the electronic components and the magnetic valve is integrated into a component group that is connected to the program control of the water-bearing device. The necessary electric connections are reduced between the individual magnetic valves and the program control due to the integration of hydraulic magnetic valves with electronic components that are used to control the magnetic valves in a component group. The complexity of the cable form for the electric connection of the hydraulic component and the electronic components is reduced, thus enabling modular construction of the related components. The equipment of the component groups can be varied according to each household device design.
专利附图（8）
