用于增强农产品冷却的冷却方法和九宫格包装配置
Cooling method and nine-down packaging configuration for enhanced cooling of produce
US-8083085-B2一种提高农产品冷却效率的九宫格包装与冷却方法。
专利摘要
本发明涵盖旨在提高冷却效率、减少对容器内容物的损坏并增加产品包装密度的包装和冷却方法及系统。本发明的系统将篮子装载到托盘中，并将托盘以优选配置装载到托盘上。托盘装载有篮子，篮子布置在托盘中使得篮子的通风槽和/或通道与托盘通风开口对齐。九个托盘以3×3配置装载到标准托盘上。此外，托盘布置成使得托盘通风开口与同一层中其他托盘的通风开口对齐。该3×3层托盘构成所谓的“九宫格”配置。如下文将讨论的，该配置相对于标准包装配置具有一些令人惊讶的冷却优势。
Original abstractThe invention encompasses packaging and cooling methods and systems designed to improve cooling efficiencies, reduce damage to the contents of containers, and increase product packing density. A system of the present invention incorporates baskets loaded into trays and trays loaded in preferred configurations on a pallet. The trays are loaded with baskets arranged in the tray so that ventilation slots and/or channels of the baskets are aligned with tray ventilation openings. Nine (9) trays are loaded onto a standard pallet in a 3 by 3 configuration. Additionally, the trays are arranged so that the tray ventilation openings are in alignment with ventilation openings of other trays of the same layer. This 3 by 3 layer of trays comprises a so-called “nine-down” configuration. As will be discussed below, his configuration has some surprising cooling advantageous standard packaging configurations.
专利附图（8）
