用于限制洗碗机精细过滤器腔室压力的系统
System for limiting pressure in a fine filter chamber for a dishwasher
US-8066821-B2用于提高洗碗机过滤效率并保持洗涤性能。
专利摘要
一种洗碗机包括洗涤室、用于向洗涤臂供应洗涤流体以清洁布置在洗涤室中的物品的洗涤系统，以及具有入口部分、出口部分和互连入口和出口部分的通道的洗涤流体歧管。过滤器腔室与洗涤流体歧管流体连接，用于从洗涤流体中去除食物残渣。在通道中设置文丘里管以建立低压区域。用于供给过滤器腔室的采样口位于低压区域。此外，在过滤器腔室的入口附近设置排放口。这样，洗涤流体以低压进入过滤器腔室以提高过滤过程的效率，而洗涤流体以高速进入洗涤臂以有效执行洗涤操作。
Original abstractA dishwasher includes wash chamber, a wash system for supplying washing fluid to wash arms to clean articles arranged in the wash chamber, and a washing fluid manifold having an inlet portion, an outlet portion and a passage interconnecting the inlet and outlet portions. A filter chamber is fluidly connected to the washing fluid manifold for removing food soil from the washing fluid. A venturi is provided in the passage for establishing a low pressure region. A sampling port for feeding the filter chamber is located in the low pressure region. In addition, a bleed port is provide near an inlet of the filter chamber. In this manner, washing fluid enters the filter chamber at low pressure to increase the efficiency of a filtering process, while washing fluid enters the wash arms at a high velocity to efficiently perform a washing operation.
专利附图（8）
