包括伸缩管组件保持器的清洁器具
Cleaning appliance including a telescopic wand assembly retainer
US-7877837-B2紧凑存储吸尘器软管和管，方便收纳。
专利摘要
一种圆筒型清洁器具，包括主体和软管及管组件，该组件包括可在缩回位置和伸出位置之间移动的伸缩管以及柔性软管，柔性软管具有连接到主体的第一端和连接到管的第二端。管和主体包括保持器，用于当管处于缩回状态且软管绕过主体时，将管可释放地附接到主体。替代地，管和主体包括保持器，用于当管处于缩回状态时，将管可释放地附接到主体的上表面。这种构造提供了紧凑的存储解决方案。
Original abstractA cleaning appliance of the cylinder type includes a main body and a hose and wand assembly including a telescopic wand movable between retracted and extended positions and a flexible hose having a first end connected to the main body and a second end connected to the wand. The wand and the main body include a retainer for releasable attaching the wand to the main body when the wand is in the retracted state and the hose passes around the main body. Alternatively, the wand and the main body include a retainer for releasably attaching the wand to an upper surface of the main body when the wand is in the retracted state. This construction provides a compact storage solution.
专利附图（8）
