具有配合切割刀片的修剪器

Trimmer with cooperating cutter blades

US-7406770-B2

提供刀片紧密配合的修剪器，用于修剪作业。

专利摘要

一种具有第一和第二切割刀片的修剪器。第一和第二切割刀片安装成使得其上的第一和第二平坦表面分别面向且基本平行于彼此。驱动器使第一和第二切割刀片中的至少一个相对于第一和第二切割刀片中的另一个移动。至少一个紧固组件具有第一和第二面向的肩部，第一和第二切割刀片位于其间。该至少一个紧固组件还具有至少一个偏置元件，其产生将第一和第二平坦切割刀片表面偏置推向彼此的力。

Original abstractA trimmer having first and second cutting blades. The first and second cutting blades are mounted so that first and second flat surfaces, respectively thereon, face and are substantially parallel to each other. A drive causes at least one of the first and second cutting blades to move relative to the other of the first and second cutting blades. At least one fastening assembly has first and second facing shoulders between which the first and second cutting blades reside. The at least one fastening assembly further has at least one biasing element that produces a force that biasably urges the first and second flat cutting blade surfaces towards each other.

专利附图（8）
