用于水体增氧、植物促生长及废水处理。
专利摘要
公开了一种氧气发射器，其是电解池。当阳极和阴极被临界距离隔开时，产生非常小的氧气微泡和纳米泡。非常小的氧气泡保持悬浮，形成过饱和氧的溶液。公开了一种用于使流动水增氧的流通式模型。公开了使用过饱和水促进植物生长。描述了将过饱和水手动、通过滴灌或在水培中施用于植物的方法。公开了通过使用氧气发射器提高溶解氧来处理废水。
Original abstractAn oxygen emitter which is an electrolytic cell is disclosed. When the anode and cathode are separated by a critical distance, very small microbubbles and nanobubbles of oxygen are generated. The very small oxygen bubbles remain in suspension, forming a solution supersaturated in oxygen. A flow-through model for oxygenating flowing water is disclosed. The use of supersaturated water for enhancing the growth of plants is disclosed. Methods for applying supersaturated water to plants manually, by drip irrigation or in hydroponic culture are described. The treatment of waste water by raising the dissolved oxygen with the use of an oxygen emitter is disclosed.
