Abstract
Disclosed is a body care brush comprising a brush holder ( 2 - 5 ) and a brush ( 1 ) that is rotatably mounted on said brush holder ( 2 - 5 ). The brush holder ( 2 - 5 ) is provided with a drive unit in which an electric motor ( 7 ) that is used for driving the brush ( 1 ) is mounted so as to be protected from the water. The brush ( 1 ) is hollow, is open at the bottom, and can be pulled over the drive unit so as to be driven by the electric motor ( 7 ) via an entraining element. The inventive body care brush provides relaxation and is comfortable and enjoyable to use, without going into contortions and applying any force.
Patent figures（8）
