来源记录显示 Expired
具有线缆管理特征的办公家具
Casegoods with cable management features
US-8087738-B2用于办公家具的线缆管理
专利摘要
具有线缆管理特征的办公和家庭办公家具产品，例如包括带有铰接检修门的基座的桌子，该铰接检修门的顶部边缘中设置有一个或多个线缆管理索环。该桌子还可以包括铰接的挡板，其顶部边缘中设置有一个或多个线缆管理索环。线缆管理索环包括多个线缆管理索环孔，以便于电线或电缆穿过线缆管理索环的布线。该桌子还可以包括具有底表面的工作表面，多个线槽附接至该底表面。桌子的各种面板包括半圆形的电线开口，以便于在电线或电缆已经穿过线缆管理索环孔布线之后进行布线。挡板包括偏置铰链组件，有利地提供了对位于挡板后面的墙壁插座的易于接近。
Original abstractOffice and home office furniture casegood products having cable management features, such as a desk including pedestals with hinged access doors having one or more cable management grommets disposed in the top edges of the hinged access doors. The desk may also include a hinged modesty panel with one or more cable management grommets disposed in a top edge thereof. The cable management grommets include a plurality of cable management grommet apertures to facilitate routing of cords or cables through the cable management grommets. The desk may also include a work surface having a bottom surface with a plurality of cord troughs attached thereto. Various panels of the desk include half-round cord openings to facilitate routing of cords and cables after having been routed through the cable management grommet apertures. The modesty panel includes an offset hinge assembly, advantageously providing ease of access to a wall outlet located behind the modesty panel.
专利附图（8）
