提供一种符合人体工学的枕头，用于支撑脊柱。
专利摘要
一种枕头，包括柔性外壳，外壳内包含多个内部分隔件，限定多个隔室。每个隔室内有填充材料。枕头具有锥形中心区域，限定中心区域纵向轴线，以及顶部区域，限定顶部区域纵向轴线，该轴线大致垂直于中心区域纵向轴线。顶部区域具有左侧部分、中心部分和右侧部分。锥形中心区域具有较厚端和较薄远端，较厚端邻近顶部区域的中心部分。至少一个内部分隔件位于锥形中心区域内，并大致垂直于中心区域纵向轴线定向。至少一个内部分隔件位于顶部区域内，并大致垂直于顶部区域纵向轴线定向。
Original abstractA pillow includes a flexible outer shell including a plurality of internal dividers that define a plurality of compartments. Stuffing material is within each of the plurality of compartments. The pillow has a tapered center region defining a center region longitudinal axis and a top region defining a top region longitudinal axis that is approximately orthogonal to the center region longitudinal axis. The top region has a left portion, a center portion, and a right portion. The tapered center region has a thicker end that is adjacent the center portion of the top region, and a thinner distal end. At least one of internal dividers is located within the tapered center region and is oriented approximately orthogonal to the center region longitudinal axis. At least one of the plurality of internal dividers is located within the top region and is oriented approximately orthogonal to the top region longitudinal axis.
专利附图（8）
