一种可放在前排座椅下方、方便取物的随身行李箱
专利摘要
尺寸和形状设计为可携带至商用飞机客舱的行李箱称为随身行李箱。小到足以放在旅客前方座椅下方的箱子必须非常小巧紧凑，通常会在旅行中干扰旅客脚部的舒适放置。所公开的行李箱包括主打包门的一个渐缩加强部分，旅客在旅行中可能希望将其脚部放置或搁置在该部分上。该主打包门被构造成可弯曲和打开，以进入一个专门设计的倾斜搁架区域，在该区域中，无需将箱子从其在前排乘客座椅下方的存放位置取出即可轻松取用瓶装饮料或化妆品。
Original abstractLuggage cases that are sized and shaped to be carried on to the passenger compartment of a commercial airplane are called carry-on luggage cases. Cases small enough to fit below the passenger seat 28 immediately in front of the traveler must be very small and compact and generally interfere with comfortable placement of the passenger's feet during travel. The disclosed luggage case 2 includes a tapering reinforced portion 22 of the main packing door 18 on which a passenger may wish to place or rest his or her feet during travel. This main packing door 18 is constructed to bend and open to give access to a specially designed slanting shelf area 12 where a bottled drink 16 or cosmetics can be easily accessed without removing the case 2 from its stowed position beneath the front passenger seat 28.
专利附图（8）
