一种用于产生细腻泡沫的发泡工具。
专利摘要
本发明旨在提供一种能够高效产生含有高比例超细气泡的奶油状泡沫的发泡工具。该发泡工具包括双层布体，该双层布体由上下重叠的布体构成，这些布体通过平织合成树脂纤维经纱和纬纱制成，使其以长度和宽度≤300μm的织物组织交替上下定位。双层布体具有夹在上下重叠布体之间的空气层。双层布体在其纵向适当中心处折叠一次，因此接合的边缘部分被组装并缝合在一起，以提供一束紧部分。在这种构造中，在束紧部分下方，提供由与上述布体相同质量的布体组装而成的发泡辅助部分。
Original abstractThe present invention aims at providing a foaming tool capable of highly efficiently producing creamy foam containing ultra fine bubbles in high proportion. The foaming tool includes a double-layered cloth body composed of vertically overlapped cloth bodies obtained by plain weaving synthetic-resin-fiber warp and wept yarns so as to cause them to alternately position up and down with weave textures of ≦300 μm length and width. The double-layered cloth body has an air layer interposed between the vertically overlapped cloth bodies. The double-layered cloth body is folded once at an appropriate center in the longitudinal direction thereof and thus joined edge portions are assembled and are stitched together to thereby provide a tab portion of gather. In such a constitution, below the tab portion, a foaming auxiliary portion produced by assembling of a cloth body having the same quality as that of the cloth described above is provided.
专利附图（8）
