用于液体容器的边缘安装式饮水辅助装置
Rim-mounted drinking aid for liquid containers
US-7828170-B2用于辅助饮水，防止溢出。
专利摘要
一种饮水辅助装置，适于与具有边缘和开口的液体容器接合，并便于用户从中饮水。该饮水辅助装置具有主体，主体的至少一部分限定U形槽，适于在边缘滑入槽中时接收容器的边缘，并在边缘和饮水辅助装置之间形成机械接合。主体还与容器接合，以在饮水辅助装置和容器之间形成摩擦配合。设置在主体上的柱或倾斜臂中的至少一个形成V形或U形漏斗，将来自容器的流体引导并居中到形成在柱中或由倾斜臂限定的孔口。当用户倾斜容器以通过孔口倒出液体时，该饮水辅助装置防止液体从容器溢出。
Original abstractA drinking aid adapted to engage, and facilitate drinking by a user from, a liquid container having a rim and an opening. The drinking aid has a body at least a portion of which defines a U-shaped groove adapted to receive the rim of the container when the rim slips into the groove and to create a mechanical engagement between the rim and the drinking aid. The body also engages the container to create a frictional fit between the drinking aid and the container. At least one of a column or angled arms disposed on the body form a V-shaped or U-shaped funnel directing and centering fluid from the container to an orifice either formed in the column or defined by the angled arms. The drinking aid prevents spillage of the liquid from the container when the user tilts the container to pour liquid through the orifice.
专利附图（8）
