一种加固结构的文件柜，用于存储文件。
专利摘要
一种文件柜包括可折叠的金属板外壳包装或单独的侧板，其限定柜体的后壁以及左侧和右侧壁。加强箱或插入件永久地固定在柜体后部内，该加强箱在后壁前方间隔开以限定加强柱，从而加固整个外壳结构。上横梁和下横梁固定在柜体前部侧壁的上角和下角，以加固柜体前部。横梁的相对端具有下垂的凸缘，其固定到一体形成在侧壁中的竖直管状边缘支撑件上。
Original abstractA file cabinet includes a foldable sheet metal housing wrapper or individual side panels which define a back wall and the left and right side walls of the cabinet. A reinforcement box or insert is permanently affixed within the back of the cabinet which reinforcement box is spaced forwardly of the back wall to define a strengthening column which rigidifies the overall housing structure. Upper and lower cross rails are secured to the upper and lower corners of the side walls at the front of the cabinet to rigidify the front of the cabinet. The opposite ends of the cross rail have depending flanges which are fixedly secured to vertical tubular edge supports formed integrally in the side walls.
专利附图（8）
