提供模块化抽屉式电器，如冰箱、酒柜等。
专利摘要
一种用于抽屉式电器系列的模块化柜体，包括限定抽屉空间的隔热衬里、机器隔间、从机器隔间通向抽屉空间的线束、从机器隔间通向抽屉空间的通道、从机器隔间通向柜体前部的空气通道以及从衬里空间通向机器隔间的排水管。抽屉式电器系列可包括冰箱、冷冻柜、制冰机、酒柜和保温抽屉。抽屉可具有两个隔间，并可保持在两个温度。抽屉包括隔热前部和料箱，并可滑动地承载在抽屉空间中。模块化柜体和控制器可用于抽屉式电器系列中的每一个成员。
Original abstractA modular cabinet for a family of drawer appliances including an insulated liner defining a drawer space, a machine compartment, a wiring harness leading from the machine compartment to the drawer space, a passage leading from the machine compartment to the drawer space and an air passage leading from the machine compartment to the front of the cabinet and a drain leading from the liner space to the machine compartment. The family of drawer appliances can include refrigerator, freezer, ice maker, wine and warming drawers. A drawer can have two compartments and can be maintained at two temperatures. The drawers include an insulated front and a bin and can be slidably carried in the drawer space. The modular cabinet and control can be used for each member of the family of drawer appliances.
专利附图（8）
