图书馆设备中的运输轨道单元和连接机构

Transporting rail unit and connection mechanism in library apparatus

US-7635245-B2

用于在图书馆等设备中沿轨道平稳运输物体。

专利摘要

一种运输轨道单元包括驱动物体到轨道上第一位置的第一驱动机构。第二驱动机构包括一个构件，当物体从轨道上第一位置前方的第二位置向前移动到第一位置时，该构件响应于来自物体的力而移位。第二驱动机构允许基于构件的移位积累弹性排斥力。运输轨道单元允许物体即使在与第一驱动机构脱离接合后，也能基于弹性排斥力继续向前移动。如果第二驱动机构介于第一驱动机构之间，则物体可以在第一驱动机构之间转移。单个运输轨道单元可以通用。这导致生产和维护成本的降低。

Original abstractA transporting rail unit includes a first driving mechanism driving the object to a first position on a rail. A second driving mechanism includes a member designed to displace in response to reception of a force from the object when the object moves forward to the first position from a second position in front of the first position on the rail. The second driving mechanism allows accumulation of an elastic repulsive force based on displacement of the member. The transporting rail unit allows the object to keep moving forward based on the elastic repulsive force even after the object is released from engagement with the first driving mechanism. If the second driving mechanism is interposed between the first driving mechanisms, the object can be transferred between the first driving mechanisms. A single transporting rail unit can be utilized in common. This results in reduction in the production and management costs.

专利附图（8）
