带有拉片激活袋的流体涂抹器

Fluid applicator with a pull tab activated pouch

US-7575384-B2

便携式流体涂抹器，拉片激活释放液体。

专利摘要

一种流体涂抹装置包括擦拭层和附着在擦拭层上以在其间形成内部空间的后层。袋位于内部空间内，流体组合物容纳在袋中限定的空腔内。袋中限定有出口结构，组合物通过该出口结构离开空腔。折翼由袋材料的延伸部分限定，并折叠到袋上以可释放地密封出口结构。折翼具有延伸部分，该延伸部分从擦拭层和后层之间延伸出足够距离以便使用者抓握。当使用者拉动折翼延伸部分时，折翼被展开并打开出口结构。流体组合物然后通过使用涂抹器从袋中压出。

Original abstractA fluid applicator device includes a wipe layer, and a back layer attached to the wipe layer to form an interior space therebetween. A pouch is positioned within the interior space, and a fluid composition is contained within a cavity defined in the pouch. Exit structure is defined in the pouch through which the composition exits the cavity. A flap is defined by an extension of the pouch material and is folded over onto the pouch so as to releasably seal over the exit structure. The flap has an extension that extends out from between the wipe layer and back layer a sufficient distance so as to be grasped by a user. When the flap extension is pulled by the user, the flap is caused to unfold and unseal the exit structure. The fluid composition is the pressed out of the pouch with use of the applicator.

专利附图（8）
