用于支撑便携式计算机并散热，避免过热。
专利摘要
一种装置包括具有耐热顶表面和相对座置边缘的底座，边缘中形成有孔。顶壳具有与底座上方对齐的内周边，并与其保持固定的升高空间关系。顶壳沿其外周边形成有孔，并由非导电和透明材料制成。细长钉具有贯穿的孔，其相对端连接到顶壳底表面和底座顶表面。轴向孔与孔和孔对齐以接收紧固件穿过。便携式计算机嵌套在底座上并配合在顶壳的内周边之间，从而有利地限制便携式计算机移动。便携式计算机与使用者的生殖器间隔开，使得便携式计算机产生的热量远离使用者的生殖器消散。
Original abstractAn apparatus includes a base that has a thermo-resistive top surface and oppositely seated edges that have apertures formed therein. A top casing has an inner perimeter aligned above the base and maintains a fixed elevated spatial relationship therewith. The top casing has holes formed along an outer perimeter thereof, and is formed from non-conductive and transparent material. Elongated pegs have bores formed therethrough and have opposed ends coupled to a top casing bottom surface and a base top surface. The axial bores are aligned with the apertures and the holes for receiving fasteners therethrough. The portable computer is nested on the base and interfitted between the inner perimeter of the top casing such that the portable computer is advantageously restricted from moving. The portable computer is spaced from the user's genitalia such that heat generated from the portable computer is dissipated away from the user's genitalia.
专利附图（8）
