用于自动关闭抽屉，提供缓冲和辅助。
专利摘要
一种用于抽屉的关闭装置，该装置具有一个带保持凹口的壳体和一个滑块，滑块具有可弯曲的弹性锁臂以接合保持凹口，以及一个弹簧，接合壳体和滑块以将滑块相对于壳体推向后方位置。弹性锁臂具有一个槽，用于容纳销，从而当抽屉从其关闭位置移开时，销的相对移动将滑块推进到弹性锁臂接合保持凹口的位置，抽屉可自由地进一步向外移动而不受关闭装置的影响。当抽屉向后朝向其关闭位置移动时，销的相对移动将使其接合弹性锁臂中的槽，进一步使其从保持凹口释放，并被弹簧推动以将抽屉移向关闭位置。
Original abstractA closing device for drawers, the device having a housing with a holding notch and a slider having a resilient latching arm that is bendable to engage the holding notch, as well as a spring that engages the housing and the slider to urge the slider to a rearward position relative to the housing. The resilient latching arm has a slot adapted to receive a pin, whereby as the drawer is moved from its closed position, the relative movement of the pin advances the slider to a position where the resilient latching arm engages the holding notch and the drawer is free to mover further outward without influence of the closing device. As the drawer is moved rearward toward its closed position, the relative movement of the pin will cause it to engage the slot in the resilient latching arm, further causing it to release from the holding notch and to be urged by the spring to move the drawer toward a closed position.
专利附图（8）
