用于容器或箱体的锁定机构，实现盖体的可靠锁定与解锁。
专利摘要
一种外壳包括基座、盖体和锁定单元。基座具有顶部开口。盖体枢接于基座，并可相对于基座从打开位置枢转到关闭位置，在关闭位置盖体覆盖基座的顶部开口。锁定单元包括用于选择性地将盖体保持在关闭位置的锁定机构。锁定机构包括形成于盖体上的锁定凸起、形成于盖体上围绕锁定凸起的容纳槽，以及枢接于基座的手柄。手柄可相对于基座从解锁位置枢转到锁定位置，在锁定位置，当盖体处于关闭位置时，手柄容纳于容纳槽中并与锁定凸起接合。
Original abstractA casing includes a base, a cover, and a locking unit. The base has a top opening. The cover is coupled pivotally to the base, and is pivotable relative to the base from an opened position to a closed position, where the cover covers the top opening of the base. The locking unit includes a locking mechanism for retaining selectively the cover in the closed position. The locking mechanism includes a locking protrusion formed on the cover, a receiving groove formed on the cover around the locking protrusion, and a handle that is coupled pivotally to the base. The handle is pivotable relative to the base from an unlocking position to a locking position, where the handle is received in the receiving groove and engages the locking protrusion when the cover is disposed at the closed position.
专利附图（8）
