用于个人卫生的便携式清洗装置。
专利摘要
一种便携式坐浴盆，包括用于储存洗涤液的圆柱形构件，以及连接到圆柱形构件的气囊部分，用于在挤压时供应空气以引起洗涤液的喷射。圆柱形构件由硬质树脂形成，并具有弧形尖端部分和至少一个喷射口。挤出构件设置在圆柱形构件中。在储存洗涤液后，喷射口由可释放的膜构件封闭。气囊部分由柔性或软质树脂形成，具有可密封的进气口，并且在不使用时，可折叠并与圆柱形构件一起包装。
Original abstractA portable bidet includes a cylindrical member for storing washing liquid, and an airbag section connected to the cylindrical member for supplying air upon squeezing to cause injection of washing liquid. The cylindrical member is formed of hard resin and has an arcuate tip end portion and at least one ejection port. An extruding member is disposed in the cylindrical member. The ejection port is closed by a releasable film member after the washing liquid is stored. The airbag section is formed of flexible or soft resin having a sealable air inlet, and when not in use, can be collapsed and packed alongside the cylindrical member.
专利附图（8）
