衣物挂架及其使用方法
Garment hanger and method for using same
US-7467737-B1用于洗涤、干燥和存放衣物。
专利摘要
一种用于洗涤、干燥和存放衣物的衣物挂架,包括挂架主体,其具有颈部支撑部分和从颈部支撑部分相对两侧向外延伸的肩部支撑部分。肩部支撑部分具有宽度,将衣物的相对两侧分开一定量,使其下端以打开状态扩张。钩结构联接到挂架主体并形成为将挂架悬挂在支撑装置上。颈部支撑部分从肩部支撑部分向上延伸,以将衣物颈部保持在打开状态。颈部开口或通道基本上不受阻碍,并具有足够的尺寸,用于洗涤衣物内部,并允许在干燥衣物时对流空气流过颈部。还公开了一种对流干燥衣物的方法。
Original abstractA garment hanger for washing, drying and storing garments including a hanger body having a neck supporting portion and shoulder supporting portions extending outwardly from opposite sides of the neck supporting portion. The shoulder supporting portions have a width separating the opposite sides of the garment by an amount which will distend the same in an open condition at its lower end. A hook structure is coupled to the hanger body and formed for hanging of the hanger from a support device. The neck supporting portion extends upwardly from the shoulder supporting portions to hold the garment neck in an open condition. The neck opening or channel is substantially unobstructed and of a sufficient size for washing of the interior of the garment and to allow convection air flow through the neck portion while drying the garment. A process of convection flow drying of the garment also is disclosed.
专利附图(6)
