来源记录显示 Expired
包括刚性壳体构件的保护壳
Protective case including rigid shell members
US-7434683-B1用于保护物品的刚性柔性结合的保护壳。
专利摘要
一种保护壳包括以大致蛤壳方式连接的第一壳体构件和第二壳体构件。每个壳体包括居中设置的刚性部分。每个壳体构件还包括第一柔性部分,其从刚性部分的第一侧延伸至邻近壳体的第一侧壁边界,从而形成壳体的顶壁边界和底壁边界的一部分。第二柔性部分也从刚性部分的第二侧延伸至邻近壳体的第二侧壁边界。拉链沿顶壁边界设置,并从第一侧壁边界延伸至第二侧壁边界。拉链将第一壳体构件的刚性部分和柔性部分与第二壳体构件的相应刚性部分及第一和第二柔性部分可操作地连接。
Original abstractA protective case includes a first shell member and a second shell member connected generally in a clam shell manner. Each shell includes a centrally disposed rigid portion. Each shell member further includes a first flexible portion, which extends from a first side of the rigid portion to adjacent the first side wall boundary of the case, so as to form a portion of the top wall boundary and the bottom wall boundary of the case. A second flexible portion also extends from the second side of the rigid portion to adjacent the second side wall boundary of the case. A zipper is disposed along the top wall boundary and extends from the first side wall boundary to the second side wall boundary. The zipper operatively connects the rigid portion and the flexible portions of the first shell member to the respective corresponding rigid portion and first and second flexible portions of the second shell member.
专利附图(8)
