用于桌子，提供可折叠腿和稳固的桌面支撑。
专利摘要
一种桌子可包括一个桌面和一个或多个腿，腿可在展开或使用位置和折叠或存放位置之间移动。桌子可包括一个或多个横杆，腿可附接到横杆。桌子还可包括一个框架，框架可包括一个或多个侧轨。横杆的尺寸和配置可设置为当腿处于展开位置时与桌子框架的至少一部分以大致刚性连接接合，当腿处于折叠位置时以松散连接接合。此外，桌子可包括一个或多个连接构件，其可设置在桌子的端部。有利地，连接构件和/或横杆可牢固地支撑桌面，并有助于防止在向桌面的一部分施加负载或力时桌面不期望地扭曲或变形。
Original abstractA table may include a table top and one or more legs and the legs may be movable between an extended or use position and a collapsed or storage position. The table may include one or more cross bars and the legs may be attached to the cross bars. The table may also include a frame and the frame may include one or more side rails. The cross bars may be sized and configured to engage at least a portion of the table frame with a generally rigid connection when the legs are in the extended position and a loose connection when the legs are in the collapsed position. In addition, the table may include one or more connecting members that may be disposed towards the ends of the table. Advantageously, the connecting members and/or cross bars may securely support the table top and help prevent the table top from undesirably twisting or deforming if a load or force is applied to a portion of the table top.
专利附图（8）
