来源记录显示 Expired
具有防回退功能的行李紧固装置
Baggage fastening device having an anti-reverse function
US-7360283-B2用于行李绑紧，防止绑带松脱回退。
专利摘要
一种行李紧固装置包括第一卡扣件、可拆卸地固定在第一卡扣件上的第二卡扣件、安装在第一卡扣件和第二卡扣件之间的绑带，以及安装在第一卡扣件上并延伸到第二卡扣件一侧的突出止动件。因此，止动件限制绑带的移动，使得在行李被绑带收紧后，绑带的可移动部分不能被释放并向后移动，从而防止绑带从行李上松脱，以提供防回退效果，防止行李紧固装置从行李上松脱。
Original abstractA baggage fastening device includes a first snapping member, a second snapping member detachably secured on the first snapping member, a strap mounted between the first snapping member and the second snapping member, and a protruding stop member mounted on the first snapping member and extended to a side of the second snapping member. Thus, the stop member restricts movement of the strap, so that the movable portion of the strap cannot be released and moved backward after the baggage is tightened by the strap, thereby preventing the strap from being loosened from the baggage so as to provide an anti-reverse effect to prevent the baggage fastening device from being loosened from the baggage.
专利附图（8）
来源状态与事件
暂无可展示的状态事件记录。
