一种从卷筒中抽取纸巾的分配器，便于装载和使用。
专利摘要
一种用于从卷筒中分配纸巾片的装置，所述卷筒中的纸巾片由多排穿孔分隔，该装置包括：底座构件，适于支撑卷筒以绕轴线旋转；第一导杆，固定地由底座承载并基本平行于轴线延伸，且与轴线间隔的距离大于卷筒的最大半径；以及第二导杆，基本平行于轴线延伸并由底座承载，以相对于第一导杆在装载位置和分配位置之间移动，装载位置便于将卷筒装载到底座上，分配位置与第一导杆间隔开一个窄间隙，卷筒的前端可自由地穿过该窄间隙。
Original abstractA device for dispensing paper towel sheets from a web of sheets arranged in a roll and separated by rows of perforations, the device comprising a base member adapted to support a roll of sheets for rotation about an axis, a first guide bar fixedly carried by the base and extending substantially parallel to the axis and spaced from the axis a distance greater than a maximum radius of the roll of sheets, and a second guide bar extending substantially parallel to the axis and carried by the base for movement, relative to the first guide bar, between a loading position facilitating loading of the roll onto the base and a dispensing position spaced from the first guide bar by a narrow gap through which a leading end of the roll may be freely received.
专利附图（8）
