用于存放钱和卡片,可开合的外壳。
专利摘要
一种钱和卡片保持组件包括具有底壁、顶壁和周边壁的外壳。周边壁中有一个周边断口,该断口与顶壁和底壁大致等距,从而限定外壳的顶部部分和底部部分。铰链将顶部部分铰接至底部部分,使得顶部和底部部分可选择性地处于打开位置或闭合位置。铰链将后壁的上部铰接至后壁的下部。第一板附接至后壁的下部并朝向底壁偏置。第二板附接至后壁的上部并朝向顶壁偏置。
Original abstractA money and card holding assembly includes a housing that has a bottom wall, a top wall and a peripheral wall. The peripheral wall has a peripheral break therein positioned generally equidistant from the top and bottom walls so that a top portion and a bottom portion of the housing are defined. A hinge hingedly couples the top portion to the bottom portion so that the top and bottom portions may selectively be positioned in an open position or a closed position. The hinge hingedly couples an upper portion of the back wall to a lower portion of the back wall. A first plate is attached to the lower portion of the back wall and is biased toward the bottom wall. A second plate is attached to upper portion of the back wall and is biased to the top wall.
专利附图(8)
