通过USB供电实现移动无线路由通信。
专利摘要
一种用于无线通信的移动通信系统，包括：电源适配器，配置为从电源接收输入功率并将输入功率适配为输出功率，该输出功率在通用串行总线（USB）标准之内；USB线缆，耦合至电源适配器以传输来自电源适配器的输出功率，该USB线缆包括至少一个USB连接器；以及路由器，配置为耦合至USB线缆并配置为接收USB线缆传输的输出功率以对路由器的组件供电，使得路由器能够使用USB线缆传输的输出功率运行，该路由器包括至少一个天线并配置为通过该至少一个天线与支持无线的通信设备进行无线通信。
Original abstractA mobile communication system for wireless communications includes a power adapter configured to receive input power from a power source and to adapt the input power to an output power, the output power being within Universal Serial Bus (USB) standards, a USB cable coupled to the power adapter to transmit the output power from the power adapter, the USB cable including at least one USB connector, and a router configured to be coupled to the USB cable and configured to receive the output power transmitted by the USB cable to power components of the router such that the router can operate using the output power transmitted by the USB cable, the router including at least one antenna and being configured to communicate wirelessly through the at least one antenna with a wireless-enabled communication device.
专利附图（8）
