用于悬挂毛巾并可紧凑收纳以晾干。
专利摘要
一种机械组件组合，为悬挂毛巾提供支撑，并可将毛巾以紧凑位置存放以便干燥。毛巾杆伸展到伸出的定位位置提供足够的间隙来悬挂毛巾。毛巾杆支撑件中的改进钥匙孔型槽具有上、下凹口。位于毛巾杆臂端部并与其成直角的整体方形枢轴销插入改进的钥匙孔中。当毛巾杆被抬起并向前拉到毛巾悬挂模式时，方形枢轴销定位在改进钥匙孔的较窄部分中，从而形成锁定位置。悬挂毛巾后，毛巾杆被向上抬起然后向后推。方形枢轴销随后在钥匙孔的较大部分中自由旋转。然后毛巾杆向下旋转到紧凑存放位置以便毛巾干燥。
Original abstractAn assemblage of mechanical components that provide support for hanging towels and for storing towels in a compact position for drying. The extension of the towel bar to an extended detented position provides sufficient clearance for hanging a towel. A modified keyhole type slot in the towel bar support has resident upper and lower notches. An integral square pivot pin located at the end of and at a right angle to the towel rod arm inserts into the modified keyhole. When the towel bar is lifted and pulled forward to the towel hanging mode, the square pivot pin is detented in the narrower portion of the modified keyhole thus creating a locked position. After towel hanging, the towel bar is lifted upwards and then pushed rearward. The square pivot pin then freely rotates in the larger portion of the keyhole. The towel bar is then rotated downward to a compact storage position for towel drying.
专利附图（8）
