可照明的可安装储物容器

Original abstractAn illuminable storage receptacle that is mounted to a motor vehicle wheel well by suction cups disposed on the cover to cast white light from the bottom and rear portions in order to illuminate the subjacent work area. Red hazard lenses are disposed in the sidewalls and an amber hazard lens is disposed in the front wall. An interior compartment is disposed therein divided by a replaceable plate to form an illumination chamber to produce the light and a storage chamber for keeping lug nuts and the like while changing the tire. A strap having hook and loop fastener elements is provided to allow the user to selectively maintain the storage compartment on a substantially horizontal plane regardless of the angle of engagement of the cover with the vehicle.
