来源记录显示 Expired
带弹簧的保护性笔记本电脑公文包
Protective laptop-briefcase with springs
US-7264116-B2用于安全携带和保护笔记本电脑，减震防撞。
专利摘要
一种用于保护和安全运输便携式计算机的保护性便携式计算机公文包。该公文包具有底部部分、可枢转地附接到底部部分的顶部盖部分、以及位于底部部分内且可容纳便携式计算机的内部柔性壳体。顶部部分具有多个弹簧、多个板和内部衬里。板在顶部部分的相对侧之间延伸，与从顶部部分延伸到网格的弹簧形成网格。内部柔性壳体限定出适于容纳便携式计算机的凹部。内部柔性壳体具有多个弹簧、多个板和内部衬里。板在相对侧之间延伸并平行于底部以形成网格。内部衬里覆盖网格和弹簧，从而吸收振动。
Original abstractA protective portable computer briefcase for protecting and securely transporting a portable computer. The briefcase has a bottom part, a top cover part pivotally attached to the bottom part, and an interior flexible case located in the bottom part and which can receive the portable computer therein. The top part has a plurality of springs, a plurality of plates, and an interior lining. The plates extend between opposing sides of the top part to create a mesh with the springs extending from the top part to the mesh. The interior flexible case defines a recess adapted to receive the portable computer. The interior flexible case has a plurality of springs, a plurality of plates, and an interior lining. The plates extend between opposing sides and are parallel to the base to create a mesh. The interior lining covers the mesh and springs, thereby absorbing vibration.
专利附图（8）
